4-Column Press Dieffenbacher, 300 Ton
TECHNICAL SPECIFICATIONS
| Capacity | 300 Ton |
| Table size | 1.500 x 1.500 mm |
| Adjustable stroke | 500 - 1.000 mm |
| Piston | ΓΈ 400 mm |
| Distance table -> ram | Minimum: 500 mm Maximal: 1.500 mm |
| Machine height | 4.000 mm |
| Under ground | 1.000 mm |
| Above ground | 3.000 mm |
| Machine weight | 18.600 kg |
4-Column Press Dieffenbacher, 300 Ton
